HDMI电缆
|
 |
|
|
|
|
产品名称：HDMI电缆
产品编号：94414-535
产品型号：HDMI(30AWG),HDMI(28AWG),HDMI(26AWG),HDMI(24AWG)
市场价格：面议 元/米
批发价格：面议 元/米
更新时间：2009.10.28
更多产品图片：
|
 |
|
 产品详细介绍 |
|
产品型号 |
HDMI(30AWG) |
HDMI(28AWG) |
HDMI(26AWG) |
HDMI(24AWG) |
|
产品编号 |
www.zgsljt.com |
|
|
|
|
芯数 |
5P*30AWG |
5P*28AWG |
5P*26AWG |
5P*24AWG |
|
+4C*30AWG |
+4C*28AWG |
+4C*26AWG |
+4C*24AWG |
|
导体规格(mm) |
10 / 7*38AWG |
10 / 7*36AWG |
10 / 7*34AWG |
10 / 7*32AWG |
|
4 / 7*38AWG |
4 / 7*36AWG |
4 / 7*34AWG |
4 / 7*32AWG |
|
导体材料 |
镀锡铜 |
镀锡铜 |
镀锡铜 |
镀锡铜 |
|
绝缘线径(mm) |
10 / 0.78 |
10 / 0.98 |
10 / 1.1 |
10 / 1.2 |
|
4 / 0.62 |
4 / 0.70 |
4 / 0.90 |
4 / 1.0 |
|
绝缘材料 |
5P 泡皮PE |
5P 泡皮PE |
5P 泡皮PE |
5P 泡皮PE |
|
4C 实芯PE |
4C 实芯PE |
4C 实芯PE |
4C 实芯PE |
|
屏蔽材料 |
铝箔/地线/
镀锡铜线编织 |
铝箔/地线/
镀锡铜线编织 |
铝箔/地线/
镀锡铜线编织 |
铝箔/地线/
镀锡铜线编织 |
|
屏蔽覆盖率 |
100% |
100% |
100% |
100% |
|
外被材料 |
PVC |
PVC |
PVC |
PVC |
|
外被线径(mm) |
6.1 |
7.4 |
8.35 |
9.4 |
|
导体电阻(Ω/100m) |
<37.63 |
<23.33 |
<14.7 |
<9.14 |
|
额定电压 |
30V |
30V |
30V |
30V |
|
额定温度 |
80℃ |
80℃ |
80℃ |
80℃ |
|
阻抗 (Ω) |
100 ±10 |
100 ±10 |
100 ±10 |
100 ±10 |
|
延迟速率 |
线对: |
线对: |
线对: |
线对: |
|
≤112ps/m Between pair: |
≤112ps/m Between pair: |
≤112ps/m Between pair: |
≤112ps/m Between pair: |
|
≤5.5ns/m |
≤5.5ns/m |
≤5.5ns/m |
≤5.5ns/m |
|
衰减 |
300KHz-825MHz
<5 |
300KHz-825MHz
<5 |
300KHz-825MHz
<5 |
300KHz-825MHz
<5 |
|
825MHz-2.475GHz
<12 |
825MHz-2.475GHz
<12 |
825MHz-2.475GHz
<12 |
825MHz-2.475GHz
<12 |
|
2.475GHz-4.125GHz
<20 |
2.475GHz-4.125GHz
<20 |
2.475GHz-4.125GHz
<20 |
2.475GHz-4.125GHz
<20 |
|
4.125GHz-5.1GHz
<25 |
4.125GHz-5.1GHz
<25 |
4.125GHz-5.1GHz
<25 |
4.125GHz-5.1GHz
<25 |
|
回波 |
>20dB |
>20dB |
>20dB |
>20dB |
|
包装长度 (m) |
1.0 / 1.8 / 3.0 |
1.0 / 1.8 / 3.0 |
1.0 / 1.8 / 3.0 |
1.0 / 1.8 / 3.0 | |
|
|
|
|
|
